Classic moisture-proof diffuser luminaire with two-part luminaire design. Housing made of shockproof, UV-resistant plastic (polycarbonate). Injected silicone-based seal with increased resistance even under extreme conditions. Diffuser made of UV-resistant opal plastic (PMMA) with excellent light transmission of up to 90% Diffuser fixed by stainless steel clips for easy installation and opening. Symmetrical light distribution. Homogeneous light distribution. Flexible and easy installation thanks to sliding quick-fix brackets made of stainless steel and diffuser with integrated gear tray as well as variable cable entry (face or rear sided). Suitable for Ceiling mounting, Suspension cable/chain, Wall (surface). Ceiling mounting stainless steel brackets and triangular brackets for pendant mounting included in delivery. MultiLumen: 2 steps adjustable luminous flux. Factory setting is "HO" (high lumen). Through-wiring (2.5mm2) as standard. Luminaire with limited surface temperature in accordance with EN 60598-2-24 for use in environments in which a deposit of conductive dust on the luminaire can be expected. Suitable for lighting in public car parks and public off-street parking spaces according to DIN 67528. Environmentally friendly and resource-saving due to replaceable components.
Technical Specifications
| Length L | 1454 mm |
|---|---|
| Width B | 102 mm |
| Height H | 85 mm |
| Weight | 2.27 kg |
| Light source | LED |
| Colour temperature | 4000 K |
| Rated luminous flux | 7200 lm | 9200 lm |
| System power | 44 W | 57 W |
| System efficiency | 161 lm/W | 164 lm/W |
| Glare evaluation RUG (4H 8H) | 26,3 | 27,1 |
| Beam angle |
down 130°/104° up 180°/180° |
| Rated life | 72000 h (L80/B50) |
| Colour rendering index (CRI) | 80 |
| Colour tolerance (McAdam) | 3 SDCM |
| Photobiological safety according to EN 62471 | Risk group 1 |
| Driver | Converter, dimmable |
| Control | DALI |
| Voltage | 220 - 240 V / 0 Hz, 50 Hz, 60 Hz |
| Luminaires on B10A fuse | 12 |
| Luminaires on B16A fuse | 20 |
| Luminaires on C10A fuse | 20 |
| Luminaires on C16A fuse | 34 |
| Inrush current / Inrush current duration | 25 A / 230 µs |
| CIE Flux Code / CEN Flux Code | 43 73 91 93 100 |
| Type of protection | IP 66 |
| Protection class | I |
| Filament test | 650°C - 30 seconds |
| Impact resistance | IK04 |
| Ambient temperature | -25 °C bis + 35 °C |
| Safety marks | D-mark |
| Conformity mark | CE , EAC , UKCA |
