Floodlight. Housing: die-cast aluminium, powder-coated. Clear glass cover. Adjustable spotlight. With mains voltage LED module.
Technical Specifications
| Length L | 136 mm |
|---|---|
| Width B | 99 mm |
| Height H | 220 mm |
| Weight | 1.1 kg |
| Light source | LED |
| Colour temperature | 3000 K |
| Rated luminous flux | 680 lm |
| System power | 10 W |
| System efficiency | 68 lm/W |
| Glare evaluation RUG (4H 8H) | 22 |
| Beam angle | 47° |
| Rated life | 40000 h (L70/B50) |
| Colour rendering index (CRI) | 80 |
| Colour tolerance (McAdam) | 3 SDCM |
| Photobiological safety according to EN 62471 | Risk group 1 |
| Driver | Not necessary |
| Control | on/off |
| Voltage | 220 - 240 V / 50 Hz |
| Luminaires on B10A fuse | 100 |
| Luminaires on B16A fuse | 160 |
| Inrush current / Inrush current duration | 15 A / 10 µs |
| CIE Flux Code / CEN Flux Code | 90 97 99 95 100 |
| Type of protection | IP 65 |
| Protection class | I |
| Filament test | 960°C - 30 seconds |
| Impact resistance | IK06 |
| Ambient temperature | -20 °C bis + 25 °C |
| Conformity mark | CE , EAC |
