LED pendant luminaire with extremely flat and frameless appearance. Middle bar made of aluminium extrusion profile, powder-coated. Transparent light guide made of UV-resistant acrylic glass (PMMA) with TWINDOT prismatic. Light control with perfectly glare-free TWINDOT technology for pleasantly gentle light with soft shadows. Even and wide indirect and direct light distribution. Direct 55%, indirect 45% light emission. 4-point steel cable suspension, steplessly adjustable. Converter integrated in the canopy (powder-coated white). Power supply through suspension cable.
Technical Specifications
| Length L | 1500 mm |
|---|---|
| Width B | 350 mm |
| Height H | 20 mm |
| Suspension length LP | 500-1200 mm |
| Weight | 7.44 kg |
| Light source | LED |
| Colour temperature | 3000 K |
| Rated luminous flux | 8100 lm |
| System power | 65 W |
| System efficiency | 125 lm/W |
| Glare evaluation RUG (4H 8H) | 17,6 |
| Beam angle |
down 91°/102° up 163°/151° |
| Rated life | 60000 h (L80/B50) |
| Colour rendering index (CRI) | 80 |
| Colour tolerance (McAdam) | 3 SDCM |
| Photobiological safety according to EN 62471 | Risk group 1 |
| Driver | Converter, dimmable |
| Control | DALI |
| Voltage | 220 - 240 V / 50 - 60 Hz |
| Luminaires on B10A fuse | 8 |
| Luminaires on B16A fuse | 13 |
| Luminaires on C10A fuse | 13 |
| Luminaires on C16A fuse | 21 |
| Inrush current / Inrush current duration | 53 A / 200 µs |
| CIE Flux Code / CEN Flux Code | 47 77 94 55 100 |
| Type of protection | IP 20 |
| Protection class | I |
| Filament test | 650°C - 30 seconds |
| Impact resistance | IK03 |
| Ambient temperature | -20 °C bis + 45 °C |
| Conformity mark | CE , EAC |
