AC-Control
985487
Modules and components
Monitoring module for monitoring individual luminaires of 2-120 W. When an AC control module is used, maintained and non-maintained luminaires can be combined in one electric circuit. Individual circuits can be switched using the inputs of the IO module. The luminaire address can be set manually via an externally accessible rotary encoding switch.
Technical Specifications
| Type of Installation | Recessed mounting |
|---|---|
| Monitoring | Luxifair AC-Control |
| Input voltage | 230 V AC (+/- 10%), 230 V DC (+/- 20%) |
| Type of protection | IP 20 |
| Protection class | II |
| Length L | 81 mm |
| Width B | 33 mm |
| Height H | 24 mm |
| Weight | 50 g |
