LINEDO 50
95030S2002.700.000
Module including Passive Infrared (PIR) sensor for movement and ambient light. System profile made of profiled steel plate, coated. Cover: plastic, white. Simple, tool-free installation of system profiles using separate accessories for cable, chain or ceiling suspension. Tool-free connection and mechanical connectors to secure. Phase can be set via patended bridge without opening the luminaire. Pre-assembled connector for DALI line. Light and movement sensor: DALI-2 sensor can be individually positioned ± 1 m over the length of the system profile. Housing of non-flammable, halogen-free plastic (polycarbonate). Detection range: 30x19 m. Light sensor range: 10-2500 lx. Installation height: 5-16 m. Example of use: Monitoring of warehouses, high-bay warehouses where there is a large installation height. Please order supply module, connection and mounting accessories separately.
Technical Specifications
| Length L | 316 mm |
|---|---|
| Width B | 122 mm |
| Height H | 250 mm |
| Weight | 1.12 kg |
| Voltage | 220 - 240 V / 50 Hz, 60 Hz |
| Type of protection | IP 40 |
| Protection class | I |
| Filament test | 650 °C |
| Impact resistance | IK03 |
| Ambient temperature | -20 °C bis + 50 °C |
| Conformity mark | CE |
