A rounded affair

PLANOX TUBE stands for high-quality replaceable components, quick and easy installation as well as adjustable beam angle. The attractive weatherproof LED luminaire with a round housing for wall, ceiling and pendant mounting is ideally suited to both industrial and architectural environments.

With a twinkle in its eye the PLANOX TUBE FARM could be described as the “Wild West version” of our well-known weatherproof luminaire. Its ammonia and dust resistant PMMA housing makes it almost indestructible and thus an unreserved and DLG-tested recommendation for permanent use in stables.

Highlights of PLANOX TUBE


  • Robust: IP67 / IK08 - High types of protection for tough requirements.
  • Combinable: Also available as an emergency luminaire in accordance with EN IEC 60598-2-22.
  • Sustainable: Environmentally friendly and resource-saving due to replaceable components. Not a disposable luminaire.
  • Tested: Qualified for use in the food and drink industry.
  • Safe: Luminaire with limited surface temperature in accordance with EN 60598-2-24.
  • Versatile: Ammonia-resistant version DLG approved.

Lighting planning

  • Powerful: High luminous flux up to 10000 lm.
  • Efficient: Good luminous efficacy of up to 162 lm/W.
  • Long service life: Extended rated LED rated 72000 h (L80).
  • Flexible: Selectable direction of light output by turning the luminaire in the retaining clips.
  • Dynamic: Versions with motion detector.
  • Reliable planning: Suitable for lighting in public car parks and public off-street parking spaces according to DIN 67528.


  • Easy installation: No need to open the luminaire for electrical connection thanks to Plug & Play connection system Wieland RST® CLASSIC.
  • Standard: Versions with through wiring.
  • Versatile: Surface and pendant mounting.
  • Flexible: Variable installation thanks to customisable positioning of retaining clips along the length of the luminaire.
  • Connected: Versions with Casambi smart+free Bluetooth® control system for wireless network.
